Description
AirTAC X-APHT803 Brass Hex Fitting Specifications
- Model: X-APHT803
- Type: Full brass hexagon pneumatic connector
- Thread standard: Metric (M5×0.8) & BSPP (G1/8") compatible
- Material: Lead-free CW617N brass alloy
- Surface treatment: Electroplated nickel (8-12μm thickness)
- Pressure rating: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 120℃
- Hex size: 13mm AF (across flats)
- Seal type: Integrated O-ring (NBR 70±5 Shore A)
- Weight: 34.5±0.8g
- Dimensions: 25mm(L) × 13mm(W) × 8mm(H)
- Thread engagement: 6.5mm minimum
- Certification: RoHS 2011/65/EU compliant
Precision-machined brass fitting with dual sealing surfaces, designed for high-vibration environments. Features 360° rotatable collar for easy tube alignment and maintenance-free operation. Anti-galling nickel plating ensures smooth thread engagement even after repeated installations.
Typical Applications:
- Pneumatic cylinder port connections
- Compressed air distribution manifolds
- CNC machine tool pneumatic circuits
- Food processing equipment (NSF-H1 grease compatible)
- Hydraulic test bench installations
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (taper threads only).
Use 18-22 N·m torque with calibrated wrench. Avoid overtightening
which may deform sealing surfaces.
