Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW601
AirTAC X-APHW601 F-Type Threaded Rotatable Tee Fitting Specifications
- Model: X-APHW601
- Type: F-type metric thread rotatable three-way connector
- Thread standard: M5×0.8 (male thread)
- Material: Anodized aluminum alloy body + PPS resin rotating sleeve
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Weight: 38g ±2g
- Dimensions: 35mm(L) × 25mm(W) × 25mm(H)
- Port angles: 360° continuous rotation capability
- Seal material: HNBR O-rings
- Surface hardness: HV400-450 (anodized layer)
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
- IP rating: IP54 (dust and splash resistant)
High-density machining tee connector with full-range positioning capability, featuring wear-compensating thread design for leak-free connections. The dual-locking flange prevents accidental disengagement during vibration. Compatible with ISO 15407-1 standard pneumatic systems. Rated for 500,000+ rotation cycles.
- Modular pneumatic circuit branching in robotics
- Tool changer interfaces on CNC machines
- Multi-axis actuator manifold connections
- Portable medical gas delivery systems
- Semiconductor wafer handling equipment
Installation note:
Apply 2-3 drops of PTFE-based lubricant on threads before initial use.
Torque specification: 0.7-1.2 N·m. Avoid overtightening beyond 150% of
recommended torque to prevent sleeve deformation.
