Airtac X-APHW Connector - Female Thread Swivel Tee X-APHW803
AirTAC X-APHW803 F-Type Threaded Rotary Tee Fitting Specifications
- Model: X-APHW803
- Type: F-Type (Female Thread) Rotary Tee Connector
- Material: Brass with nickel-plated surface
- Thread Standard: PT1/8 (BSPP)
- Pressure Range: 0.05-1.5 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile Rubber)
- Port Configuration: 3-way equal distribution
- Rotation Angle: 360° continuous rotation
- Weight: 35g ±2g
- Dimensions: 20mm(L) × 20mm(W) × 20mm(H)
- Torque Resistance: ≤2.5 N·m
- Leakage Rate: ≤3 bubbles/min (ISO 6952 standard)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
A precision rotary tee connector featuring maintenance-free rotation mechanism with dual ball bearing structure. The chrome-plated brass body ensures corrosion resistance in humid environments. Designed for multi-directional pneumatic line branching without flow restriction, with audible click feedback at 90° rotation intervals.
- Modular pneumatic circuit distribution in automation cells
- Tool-changing mechanisms on CNC machines
- Multi-axis robotic arm pneumatic supply systems
- Laboratory equipment gas line manifolds
- Packaging machine air jet control units
Installation protocol:
Hand-tighten initially with 1/2 turn past finger-tight position.
Use thread sealant (LOCTITE 545) for pressure >0.8 MPa applications.
Maximum recommended rotation speed: 15 RPM under load.
