Airtac X-APK Connector-5-Way X-APK10
AirTAC X-APK10 Five-Way Fitting Technical Details
- Model: X-APK10
- Type: Compact modular five-way connector block
- Material: Nickel-plated brass body
- Port configuration: 5 ports (P, A, B, EA, EB)
- Thread standards: PT1/8 (NPT1/8 optional)
- Max operating pressure: 1.0 MPa
- Min operating pressure: 0.05 MPa
- Temperature range: -5℃ to 80℃
- Seal material: NBR (Nitrile rubber)
- Mounting style: Sub-base compatible (ISO 15407-2)
- Weight: 24.5g ±0.3g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H)
- Surface treatment: Electroless nickel plating (5-8μm)
Modular pneumatic manifold designed for space-constrained valve arrangements. Features integrated flow paths with 50% reduced pressure drop compared to conventional fittings. The cross-drilled ports enable multi-directional piping configurations. Includes built-in silencer mounting slots.
- Modular pneumatic valve island assemblies
- Robotic end-effector control systems
- Multi-axis CNC machine tool manifolds
- Compact packaging line actuators
- Medical device pneumatic control units
Installation guidelines:
Use 0.8-1.2Nm torque for port connections. Apply Loctite 545
on threads for vacuum applications. Avoid axial misalignment
during manifold stacking - maximum cumulative tolerance 0.15mm.
| Property | Property Value |
|---|---|
| sku | X-APK10 |
