Airtac X-APKB Connector - Threaded 5 Port X-APKB1001
AirTAC X-APKB Threaded Five-Way Connector X-APKB1001 Technical Details
- Model: X-APKB1001
- Type: 5-port threaded manifold (5/3-way function)
- Body material: Nickel-plated brass (ISO 1179 standard)
- Thread specification: G1/8 (BSPP) female ports
- Port configuration: 1 inlet (P), 2 outlets (A/B), 2 exhausts (R/S)
- Tube compatibility: Ø10mm polyurethane/nylon tubing
- Pressure range: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -5℃ to 80℃ (operating fluid)
- Weight: 152g ±3g
- Dimensions: 58mm(L) × 35mm(W) × 48mm(H)
- Seal material: NBR (Nitrile) with PTFE backup rings
- Flow coefficient (Cv): 1.2
- Leakage rate: <10 cm³/min @ 0.5 MPa
Multi-functional pneumatic distribution block featuring integrated exhaust mufflers and corrosion-resistant construction. Designed for compact valve manifolds requiring multiple flow paths, with diamond-knurled surfaces for tool-free manual operation. Compatible with ISO 15407-1 standard valves.
- Modular pneumatic control systems
- Automated assembly line clamping units
- Textile machinery air distribution
- Plastic injection molding machine manifolds
- Multi-axis pneumatic actuator synchronization
Installation note:
Apply 2-3 wraps of PTFE tape on male threads (clockwise winding).
Maximum tightening torque: 15 N·m. Install exhaust silencers vertically
downward to prevent liquid accumulation. Avoid side-loading during
piping connections.
Compatibility notice:
Not recommended for oxygen systems or acetylene applications.
Use AirTAC APKC series for vacuum circuits. Always flush system
before installation to remove metal particles.
| Property | Property Value |
|---|---|
| sku | X-APKB1001 |
