Airtac X-APKB Connector - Threaded 5 Port X-APKB1202
AirTAC X-APKB1202 Threaded Manifold Specifications
- Model: X-APKB1202
- Type: 5-port threaded manifold (ISO standard)
- Port configuration: 1 inlet (P), 2 outlets (A/B), 2 exhausts (R/S)
- Thread specification: G1/8 (BSPP) female ports
- Material: Anodized aluminum alloy (AL6063-T5)
- Max working pressure: 1.0 MPa
- Operating temperature: -5℃ to 80℃
- Surface hardness: HV 12°±2°
- Installation torque: 5-7 N·m (for valve mounting)
- Port pitch: 18 mm (standard CETOP pattern)
- Weight: 230±5g
- Dimensions: 96mm(L) × 30mm(W) × 38mm(H)
- Seal material: HNBR (Hydrogenated Nitrile) O-rings
- Compliance: RoHS 2.0 compliant
Modular pneumatic manifold designed for multi-valve integration in compact systems. Features precision-machined flow channels with 0.8μm surface finish for optimal airflow. The corrosion-resistant anodized finish ensures durability in humid environments. Compatible with all ISO 15407-1 compliant pneumatic valves.
- Multi-axis pneumatic actuator control systems
- Automated assembly line sequencing circuits
- Packaging machine multi-cylinder synchronization
- Semiconductor handling equipment manifolds
- Automotive tire inflation systems
Installation note:
Apply liquid thread sealant (LOCTITE 577 recommended) on male threads.
Maximum side load tolerance: 15N at valve mounting points.
Use torque wrench for consistent installation force.
| Property | Property Value |
|---|---|
| sku | X-APKB1202 |
