Airtac X-APKB Connector - Threaded 5 Port X-APKB402
AirTAC X-APKB402 Threaded Manifold (5-Port) Specifications
- Model: X-APKB402
- Type: 5-port threaded manifold with G1/4 ports
- Thread standard: ISO228 (G-thread) / NPT optional
- Material: Anodized aluminum alloy (AL6063-T5)
- Surface hardness: ≥90HB
- Max working pressure: 1.0 MPa
- Proof pressure: 1.5 MPa
- Operating temperature: -20℃ to 80℃
- Port configuration: 1 input (P), 2 outputs (A/B), 2 exhausts (R/S)
- Seal material: HNBR (High Nitrile Rubber)
- Weight: 228±5g
- Dimensions: 72mm(L) × 40mm(W) × 40mm(H)
- Mounting torque: 12-15 N·m (for port connections)
- Vibration resistance: 10-55Hz with 1.5mm amplitude
High-density pneumatic distribution block with precision-machined flow channels, designed for compact valve island configurations. Features dual-row exhaust ports and anti-vibration thread locking design. The anodized surface provides corrosion resistance in humid environments. Compatible with ISO15407-2 standard valves.
- Modular pneumatic control systems
- Multi-valve stacking in robotic end effectors
- CNC machine tool pneumatic circuits
- Packaging line actuator clusters
- Semiconductor handling equipment
Installation note:
Apply PTFE tape on male threads with 1.5-2 wraps maximum.
Use counter-clockwise rotation for NPT variant installation.
Maintain 20mm clearance below manifold for tubing routing.
- Direct mounting with AP11/AP12 series valves
- Adapter kits available for SMC SY300/400 series
- Supports up to 4-block manifold stacking
| Property | Property Value |
|---|---|
| sku | X-APKB402 |
