Airtac X-APKB Connector - Threaded 5 Port X-APKB6M5
AirTAC X-APKB Threaded Manifold X-APKB6M5 Technical Specifications
- Model: X-APKB6M5
- Type: 5-port threaded manifold (straight flow path)
- Thread specification: M5×0.8 (ISO metric fine)
- Port configuration: 1 input (P), 2 outputs (A/B), 2 exhausts (R/S)
- Material: Brass with nickel-plated surface
- Seal material: NBR (Nitrile) O-rings
- Max operating pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port-to-port spacing: 6mm (center distance)
- Surface roughness: Ra ≤3.2μm
- Weight: 18.5g ±0.5g
- Dimensions: 30mm(L) × 24mm(W) × 18mm(H)
- Compatibility: Works with Φ6mm pneumatic tubing
- Certification: RoHS compliant
Precision-engineered 5-way manifold with compact footprint, designed for multi-valve integration in pneumatic control systems. Features leak-resistant tapered thread design and color-coded port markings (P-red, A/B-blue, R/S-black) for error-free installation. Electroless nickel plating provides corrosion resistance in humid environments.
- Modular pneumatic valve island assemblies
- Robotic gripper control circuits
- Automated production line sequencing systems
- Medical device pneumatic logic units
- Packaging machine actuator clusters
Installation guidelines:
Apply 2-3Nm torque during installation. Use thread sealant only on male threads,
avoiding contact with O-rings. Maximum angular deviation ≤3° from manifold base plane.
| Property | Property Value |
|---|---|
| sku | X-APKB6M5 |
