Airtac X-APKB Connector - Threaded 5 Port X-APKB6M8
AirTAC X-APKB6M8 Threaded Manifold Fitting Technical Details
- Model: X-APKB6M8
- Type: 5-port manifold (PTT-PTT configuration)
- Thread standard: Metric fine (M8×1.0 thread pitch)
- Port configuration: 1 input, 4 outputs (1/8" NPT equivalent flow capacity)
- Max operating pressure: 1.0 MPa (145 psi)
- Burst pressure: ≥3.0 MPa
- Material: Aluminum alloy 6063-T5 (anodized surface)
- Seal type: Dual O-ring design (NBR 70±5 Shore A)
- Temperature range: -20℃ to 80℃ (continuous duty)
- Weight: 82g ±3%
- Dimensions: 50mm(L) × 30mm(W) × 30mm(H)
- Surface hardness: HV 120-150
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Certifications: RoHS compliant, ISO 9001 manufacturing
High-density pneumatic distribution block featuring precision-machined internal channels (Φ3.5mm equivalent diameter) for minimal pressure drop. The dual-seal design prevents cross-port leakage even under pulsating loads. Nickel-plated ports enhance corrosion resistance in humid environments.
- Multi-actuator control in CNC tool changers
- Modular pneumatic test benches
- Compact robotic gripper systems
- Medical device pneumatic distribution nodes
- Food processing equipment air routing
Mounting guidance:
Apply 2.5-3.5 N·m torque during installation. Use thread sealant only on male threads,
avoiding contamination of O-ring grooves. Maximum angular misalignment tolerance: ±1.5°.
| Property | Property Value |
|---|---|
| sku | X-APKB6M8 |
