Airtac X-APKB Connector - Threaded 5 Port X-APKB803
AirTAC X-APKB803 Threaded Five-Way Fitting Technical Details
- Model: X-APKB803
- Type: Threaded pentaport (5-way) manifold connector
- Body material: Anodized aluminum alloy (AL6063-T5)
- Seal material: HNBR rubber (hydrogenated nitrile)
- Thread standard: G1/8 (ISO228-1 compliant)
- Port configuration: 1 input, 4 output ports
- Pressure rating: 0.2-1.0 MPa (29-145 psi)
- Temperature range: -20℃ to 80℃ (continuous operation)
- Installation torque: 1.5-2.0 N·m max
- Surface treatment: Black electrophoretic coating
- Weight: 75g ±2g
- Dimensions: 25mm(L) × 25mm(W) × 25mm(H)
- Flow capacity: 300 NL/min @ 0.5 MPa
- Leakage rate: ≤0.1 mL/min @ 0.6 MPa
Precision-engineered pneumatic distribution block featuring laser-etched port markings for error-proof installation. The chamfered edges and color-coded sealing rings enable quick visual identification during maintenance. Optimized internal flow channels reduce pressure drop by 18% compared to standard manifolds.
- Modular pneumatic control systems in assembly lines
- Multi-actuator synchronization in packaging machinery
- Vacuum circuit distribution for material handling robots
- Compressed air branching in semiconductor wafer handlers
- Tool changer interfaces for CNC automation cells
Installation protocol:
Apply 2-3 drops of PTFE-based thread sealant (NEVER use tape) and torque in
cross-pattern sequence. Allow 30-minute cure time before pressurization.
- Works with AirTAC SMCV-20 series valves
- Compatible with Festo QS series quick connectors
- Tested with 6mm OD polyurethane tubing (transparent/anti-static variants)
| Property | Property Value |
|---|---|
| sku | X-APKB803 |
