Airtac X-APKB Connector - Threaded 5 Port X-APKB8M8
AirTAC X-APKB8M8 Threaded Five-way Fitting Specifications
- Model: X-APKB8M8
- Type: Brass five-way threaded manifold
- Thread standard: M8×1.25 (male threads on all ports)
- Port configuration: 5 ports (1 inlet, 4 outlets)
- Material: Lead-free brass CW617N
- Surface treatment: Electroless nickel plating (5-8μm)
- Pressure rating: 0.2-1.0 MPa (29-145 psi)
- Temperature range: -20℃ to 120℃ (-4℉ to 248℉)
- Seal material: NBR/FKM optional
- Torque limit: 12-15 N·m maximum
- Weight: 48g ±2g
- Dimensions: 28mm(L) × 28mm(W) × 24mm(H)
- Compliance: RoHS 2.0 compliant
High-density pneumatic distribution block designed for compact pneumatic systems requiring multi-directional flow control. Features precision-machined internal channels with 1.6μm surface roughness for optimal airflow. Anti-vibration design maintains seal integrity under mechanical stress.
- Modular pneumatic control panels
- Robotic end-effector tooling systems
- CNC machine tool clamping circuits
- Medical device pneumatic manifolds
- Semiconductor handling equipment
Installation note:
Apply 242 Loctite® on threads and tighten in crisscross pattern.
Maximum 90° rotation after hand-tightening. Avoid overtightening -
use calibrated torque wrench for assembly.
| Property | Property Value |
|---|---|
| sku | X-APKB8M8 |
