Description
AirTAC X-APKJ4 Insertion-Type 5-Way Junction Specifications
- Model: X-APKJ4
- Type: Insertion manifold with 5 ports (P, A, B, R1, R2)
- Thread standard: M5 (G1/8 optional)
- Material: Anodized aluminum alloy body, NBR seals
- Max operating pressure: 1.0 MPa
- Temperature range: -5℃ to 80℃
- Flow capacity: 350 L/min (ANR)
- Mounting style: Push-in locking mechanism
- Tube compatibility: Ø4mm polyurethane/nylon tubing
- Weight: 85g ±2g
- Dimensions: 48mm(L) × 34mm(W) × 26mm(H)
- Port spacing: 10mm center-to-center
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Modular pneumatic manifold designed for space-constrained multi-actuator systems. Features dual exhaust ports (R1/R2) for independent flow control and leak-free O-ring sealed connections. Gold-plated brass inserts ensure corrosion resistance and 500,000+ cycle durability.
Ideal for:
- Multi-axis pneumatic gripper configurations
- Compact PLC-controlled automation cells
- Laboratory analytical instrument valve clusters
- Semiconductor handling equipment manifolds
- Mobile robotics air distribution systems
Installation tip:
Apply silicone-free lubricant to tube ends before insertion.
Maximum 90°C ambient temperature with derated pressure (0.7MPa).
Use torque ≤0.25N·m during port tightening.
| Property | Property Value |
|---|---|
| sku | X-APKJ4 |
