Airtac X-APKJ Push-In 5-Way Fitting X-APKJ6
AirTAC X-APKJ6 Push-in Fitting 5-Way Connector Specifications
- Model: X-APKJ6
- Type: Push-in Fitting, 5-way connector (Insertion Type)
- Material: Brass (Nickel-plated surface)
- Thread Standard: PT1/8 (BSPP) or NPT1/8 optional
- Port Configuration: 5 ports (1 inlet, 4 outlets)
- Port Size: 1/8" (M5 thread compatible)
- Operating Pressure: 0.05–1.0 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: NBR (Nitrile Rubber) standard, FKM (Viton) optional
- Tube Compatibility: Ø4mm (OD) polyurethane/nylon tubing
- Leakage Rate: ≤0.1 NL/min under 0.5 MPa
- Weight: 28g ±0.5g
- Dimensions: 28mm(L) × 18mm(W) × 18mm(H)
- Surface Roughness: Ra ≤3.2μm
- Vibration Resistance: 10–55Hz, 1.5mm amplitude
Precision-engineered 5-way pneumatic connector featuring tool-free tube insertion for rapid assembly. The corrosion-resistant nickel plating ensures durability in humid environments, while the 360° rotatable ports enable flexible piping layouts. Includes built-in tube retention claws and O-ring seals for vibration-resistant connections.
- Modular pneumatic control systems
- PLC-controlled automation machinery
- Medical device gas distribution units
- Packaging line air circuit branching
- Robotic end-effector pneumatic networks
- Semiconductor manufacturing equipment
Installation protocol:
Insert tubing until audible "click" (minimum insertion depth 12mm).
For maintenance, depress red release collar while pulling tubing.
Recommended torque: 1.2–1.5N·m when using wrench flats.
Avoid overtightening – maximum torque 2.0N·m.
| Property | Property Value |
|---|---|
| sku | X-APKJ6 |
