Airtac X-APMT Connector - Full Brass Bulkhead Straight X-APMT4
AirTAC X-APMT4 Full Brass Bulkhead Straight Fitting Specifications
- Model: X-APMT4
- Type: Bulkhead straight through fitting (male to male)
- Material: Brass (nickel-plated surface)
- Port size: PT1/8 (BSP 1/8) dual ends
- Thread length: 10mm (both sides)
- Pressure rating: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (nitrile) O-ring
- Hex size: 12mm wrench flat
- Weight: 28g ±1g
- Dimensions: 35mm(L) × 12mm(W) × 12mm(H)
- Vibration resistance: ≤5Hz @ 2.5mm amplitude
- Certification: RoHS compliant
Heavy-duty brass bulkhead connector designed for permanent through-panel installations in pneumatic systems. Features dual sealing surfaces with precision-machined threads and corrosion-resistant nickel plating. The 360° rotatable hex design enables tool access from any angle during maintenance.
- Machine tool pneumatic cabinet penetrations
- Compressed air distribution panels
- Food processing equipment (corrosion-resistant)
- Marine automation systems (saltwater resistant)
- Semiconductor manufacturing gas lines
Installation protocol:
Apply 1.5-2 wraps of PTFE tape on male threads. Tighten with controlled torque
(max 2.5N·m) using backup wrench on panel nut. Perform pressure test at 1.5×
working pressure after installation.
Avoid using with:
Ethylene glycol mixtures, halogen gases, or media exceeding 80℃. Not compatible
with PTFE tape containing silicone additives.
| Property | Property Value |
|---|---|
| sku | X-APMT4 |
