Airtac X-APV Elbow 2-Way Fitting X-APV12
AirTAC X-APV12 L-Type 2-Port Fitting Technical Details
- Model: X-APV12
- Type: L-shaped 2-way pneumatic connector
- Thread specification: G1/8 (BSPP) female threads both ports
- Material: Brass (CuZn39Pb3) with nickel plating
- Max working pressure: 1.5 MPa (217 psi)
- Temperature range: -5℃ to 80℃ (non-freezing conditions)
- Installation torque: 1.5-2.0 N·m recommended
- Seal type: Embedded O-ring (NBR material)
- Weight: Approx. 48g ±2g
- Dimensions: 30mm(L) × 18mm(W) × 16mm(H)
- Flow coefficient (Cv): 0.12
- Surface hardness: HV0.3 120-200
- Protection rating: IP40 (dust protected)
90° angled pneumatic fitting featuring corrosion-resistant nickel plating and precision-machined flow paths. The compact L-shape design enables space-saving plumbing configurations while maintaining laminar airflow. Compatible with standard 8mm OD pneumatic tubing via push-to-connect installation (tube retention force >35N).
- Manifold-to-actuator connections in robotic arms
- Vacuum circuit branching in packaging machinery
- Tool changer interfaces for CNC equipment
- Compressed air distribution in dental chairs
- Sensor mounting brackets with air purge lines
Installation tip:
Apply thread sealant (PTFE tape or liquid sealant) to male threads only.
Avoid overtightening - use torque wrench for critical assemblies.
Maximum angular misalignment tolerance: ±3°.
