Airtac X-APX Adapter - Y-Type Threaded Tee X-APX602
AirTAC X-APX602 Y-Type Threaded Tee Fitting Technical Details
- Model: X-APX602
- Type: Y-shaped pneumatic tee connector (female thread)
- Material: Brass with nickel plating (corrosion-resistant finish)
- Thread standard: BSPP (G-thread) / NPT optional
- Port size: 1/8" (PT1/8/NPT1/8)
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Seal material: NBR (Nitrile rubber) inserts
- Weight: 48g ±2g
- Dimensions: 24mm(H) × 24mm(W) × 28mm(L)
- Surface hardness: ≥HV200
- Leakage rate: ≤3.5×10⁻³ Pa·m³/s under rated pressure
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered Y-connector featuring triple-port flow distribution with 120° branch angle for balanced pneumatic circuits. The hexagon base allows tool-assisted tightening, while the electroplated surface prevents oxidation in humid environments. Compatible with ISO 1179-1 standards.
- Pneumatic system branching in automation equipment
- Air tool manifold connections
- Robotic arm pneumatic networks
- Compressed air distribution in packaging machinery
- Laboratory gas line splitting
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (clockwise direction).
Tighten to 12-15 N·m torque using a crowfoot wrench. Avoid overtightening
to prevent port deformation. Test with 0.8 MPa air pressure after assembly.
