Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M5
AirTAC X-APX6M5 Y-Type Threaded Tee Fitting Specifications
- Model: X-APX6M5
- Type: Y-shaped 3-way brass tee
- Thread standard: Metric fine thread (M5×0.8)
- Material: Brass with nickel plating (stainless steel variant available)
- Pressure range: 0.05-1.5 MPa (7-217 PSI)
- Temperature range: -20℃ to 80℃ (NBR seals)/150℃ (FKM seals optional)
- Port configuration: Three M5 female threaded ports at 120° angles
- Surface treatment: Electroless nickel plating (3-5μm thickness)
- Seal material: Standard NBR, optional FKM/Viton
- Weight: 12.5g ±0.3g
- Dimensions: 25mm (length) × 20mm (width) × 20mm (height)
- Flow coefficient: Cv≈0.15
- Leakage rate: ≤3 bubbles/min under 0.5 MPa air pressure
- Certification: RoHS compliant, ISO 9001 manufacturing
Precision-engineered Y-shaped pneumatic connector featuring equal flow distribution across all ports. The 120° angled design minimizes pressure drop (ΔP ≤0.02 MPa at 1 MPa input) while enabling compact plumbing configurations. Nickel-plated brass construction resists corrosion in humid environments (96hr salt spray test passed).
- Modular pneumatic manifolds in assembly robots
- Air signal distribution in CNC machine tooling
- Miniature compressed air networks in semiconductor equipment
- Medical device pneumatic control systems
- Photovoltaic panel cleaning robot air circuits
Installation guidelines:
Apply 2-3Nm torque during installation using 7mm hex key.
Use liquid thread sealant (PTFE tape not recommended).
Align flow arrow (marked on body) with primary supply line.
Perform pressure test at 1.8×system pressure after assembly.
| Property | Property Value |
|---|---|
| sku | X-APX6M5 |
