Airtac X-APX Adapter - Y-Type Threaded Tee X-APX6M6
AirTAC X-APX6M6 Y-Type Threaded Tee Specifications
- Model: X-APX6M6
- Type: Y-shaped pneumatic tee connector
- Thread standard: Metric fine thread (M)
- Thread size: M6×1.0 (6mm major diameter, 1.0mm pitch)
- Material: Nickel-plated brass (base), NBR seals
- Operating pressure: 0.1-1.0 MPa
- Temperature range: -20℃ to 80℃ (with intermittent peaks up to 120℃)
- Seal hardness: 70±5 Shore A
- Weight: 12.5g ±0.3g
- Dimensions: 20mm (L) × 18mm (W) × 16mm (H)
- Port configuration: Three M6 female threads arranged at 120° angles
- Surface roughness: Ra ≤3.2μm
- Pressure drop: ≤0.02 MPa at 5 L/min flow rate
Precision-machined Y-branch connector featuring corrosion-resistant nickel plating and zero-leak design. The 120° angled ports enable compact piping layouts in 3D space, with hex flats for wrench tightening. Compatible with air, inert gases, and water-based fluids when using standard NBR seals.
- Modular pneumatic circuit distribution in robotics
- Coolant line branching for CNC machines
- Vacuum system manifolds in packaging equipment
- Sensor air supply splitting in semiconductor tools
- Medical gas line accessories
Installation note:
Apply thread sealant only on male threads (not female ports).
Maximum recommended torque: 1.5 N·m. Avoid overtightening
which may distort the NBR sealing rings.
| Property | Property Value |
|---|---|
| sku | X-APX6M6 |
