Airtac X-APX Adapter - Y-Type Threaded Tee X-APX803
AirTAC X-APX803 Y-Type Threaded Tee Fitting Technical Details
- Model: X-APX803
- Type: Y-Type (120° branch) pneumatic tee connector
- Thread Standard: Metric (M5×0.8) female threads
- Material: Brass with nickel plating (CuZn39Pb3)
- Pressure Range: 0.05-1.5 MPa (7-217 PSI)
- Temperature Range: -20℃ to 80℃ (continuous use)
- Seal Type: Integrated NBR O-ring seal
- Surface Finish: Electroless nickel coating (8-12μm thickness)
- Weight: 18.5±0.5g
- Dimensions: 28mm (H) × 22mm (W) × 22mm (D)
- Flow Capacity: 350 NL/min @ 0.5MPa
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: RoHS compliant, ISO 9001:2015
Precision-engineered Y-connector featuring optimized flow channels for minimal pressure drop. The 120° branch design enables compact piping layouts in tight spaces while maintaining excellent leak resistance through dual-contact sealing surfaces. Nickel plating provides enhanced corrosion protection against humid environments.
- Modular pneumatic circuit branching in automation equipment
- Air distribution in multi-axis robotic systems
- Compressed air networks for packaging machinery
- Vacuum system manifolds in electronic assembly lines
- Medical gas line distribution components
Installation Guidelines:
Apply 0.3-0.5Nm torque during assembly. Use thread sealant only on male threads,
avoiding contact with O-ring surfaces. For vertical installations, position Y-branch
horizontally to prevent particle accumulation. Compatible with 6mm OD pneumatic tubing.
| Property | Property Value |
|---|---|
| sku | X-APX803 |
