Airtac X-APX Adapter - Y-Type Threaded Tee X-APX8M8
AirTAC X-APX Y-Type Threaded Tee Connector X-APX8M8 Technical Details
- Model: X-APX8M8 (Y-Type Tee)
- Thread Standard: Metric fine thread (M)
- Port Configuration: 1 input / 2 output (T-shaped flow division)
- Thread Size: M8×1.0 (ISO 228-1 compliant)
- Material: Lead-free brass (CuZn39Pb3) with electroless nickel plating
- Max Working Pressure: 1.5 MPa (217 PSI)
- Burst Pressure: ≥4.5 MPa
- Temperature Range: -20℃ to 80℃ (NBR seals)
- Seal Material: Oil-resistant NBR (Nitrile rubber)
- Surface Treatment: Matte finish anti-corrosion coating
- Weight: 28±2g
- Dimensions: 32mm(L) × 24mm(W) × 24mm(H)
- Flow Coefficient (Cv): 0.15
- Leakage Rate: ≤3 bubbles/min (ISO 6952 test standard)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- IP Rating: IP54 (dust protected, water splashed)
Precision-engineered Y-shaped pneumatic tee connector featuring triple-ported M8×1.0 threads for compact piping systems. The asymmetrical 60° branch angle optimizes airflow distribution while minimizing pressure drop. Nickel-plated construction prevents galvanic corrosion when used with aluminum manifolds. Compatible with all standard 8mm OD pneumatic tubing through push-in fittings.
- Modular pneumatic circuit branching in robotic grippers
- Air supply distribution for CNC machine tool clamps
- Multi-actuator control systems in packaging machinery
- Vacuum circuit splitting for pick-and-place devices
- Laboratory instrument air line networks
Installation Protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 12-15N·m torque using crowfoot wrench.
Avoid direct contact with cutting fluids. Perform pressure test at 1.1× system pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-APX8M8 |
