Airtac X-EPEW Adapter - T-Type Reducing Tee X-EPEW64
AirTAC X-EPEW64 T-Type Reducing Tee Fitting Technical Details
- Model: X-EPEW64
- Type: T-shaped reducing union with metric threads
- Body material: Lead-free brass (CuZn39Pb0.5) with nickel plating
- Seal material: NBR/FKM (optional fluorocarbon)
- Thread standards: ISO 228 G-threads (BSPP)
- Port configuration: 1/8" (G1/8) main line × 2×G1/8 branch × 6mm compression
- Pressure rating: 0.05-1.5 MPa (operating), 2.2 MPa burst
- Temperature range: -20℃ to 150℃ (NBR), -20℃ to 200℃ (FKM)
- Surface hardness: ≥HV200 nickel layer
- Weight: 82g ±3%
- Dimensions: 38mm(L) × 24mm(W) × 34mm(H)
- Flow coefficient: Cv≈0.15
- Vibration resistance: 10-2000Hz, 15G acceleration
- Certifications: RoHS compliant, REACH SVHC-free
Precision-engineered flow distribution component featuring corrosion-resistant nickel plating and dual sealing options. The asymmetrical T-design enables compact system layouts while maintaining 360° rotatable branch ports. Includes integrated O-ring groove for leak-proof compression connections.
- Pneumatic circuit branching in robotic end effectors
- Coolant line distribution for CNC machining centers
- Vacuum system manifolds in packaging machinery
- Medical gas line reducers (oxygen/nitrogen systems)
- Hydraulic test bench instrumentation
Installation protocol:
Apply 2-3Nm torque during assembly. Use thread sealant only on male ports.
Align flow arrows with main direction. Pressure test at 1.1×max operating
pressure for 15min post-installation.
| Property | Property Value |
|---|---|
| sku | X-EPEW64 |
