Airtac X-EPEW Adapter - T-Type Reducing Tee X-EPEW86
AirTAC X-EPEW86 T-Type Reducer Tee Fitting Specifications
- Model: X-EPEW86
- Type: T-shaped reducer tee (male thread to dual female threads)
- Material: Nickel-plated brass (ISO 1179 compliant)
- Thread Standards:
- Main port: G1/8 (BSPP)
- Branch ports: M5×0.8 (metric)
- Pressure rating: 0.3–1.5 MPa (43.5–217.5 PSI)
- Temperature range: -20℃ to 150℃ (non-condensing)
- Seal type: Integrated O-ring (NBR material)
- Surface treatment: Electroless nickel plating (8–12μm thickness)
- Weight: 48g ±2g
- Dimensions:
- Length (port-to-port): 34mm
- Width (branch span): 22mm
- Height: 18mm
- Vibration resistance: ≤10Hz @ 2mm amplitude
- Certification: RoHS compliant
Precision-engineered flow distribution fitting with asymmetric port sizing, featuring corrosion-resistant construction and leak-proof metal-to-metal sealing. The stepped thread design ensures secure connections in high-vibration environments while maintaining 360° rotational flexibility during installation.
- Pneumatic circuit branching in robotic end effectors
- Coolant line distribution for CNC machinery
- Vacuum system pressure balancing
- Modular instrumentation air supply networks
- Compressed air tool manifolds
Installation protocol:
Apply 1.5–2 wraps of PTFE tape on male threads. Tighten to 12–15 N·m torque using crowfoot wrench.
Avoid aligning branch ports downward in particulate-heavy environments.
| Property | Property Value |
|---|---|
| sku | X-EPEW86 |
