Airtac X-EPH External Hex Elbow Connector X-EPH1002
AirTAC X-EPH Hexagonal Elbow Joint X-EPH1002 Technical Specifications
- Model: X-EPH1002
- Type: Swivel-type adjustable elbow joint
- Thread specification: M10×1.25 (male thread)
- Material: Aluminum alloy 6061-T6 (anodized)
- Seal material: NBR (nitrile rubber)
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Swivel angle: ±5° axial adjustment range
- Torque resistance: 3.5 N·m max
- Weight: 48±2g
- Dimensions: 34mm (L) × 24mm (W) × 24mm (H)
- Surface hardness: HV 120±10
- Protection rating: IP40 (standard configuration)
Precision-engineered swivel joint featuring dual-locking hex design for secure pneumatic line connections. The chrome-plated steel swivel ball maintains smooth rotation even under vibration, while the 360° rotatable collar enables tool-free installation alignment. Rated for 500,000+ duty cycles with <2° angular drift.
- Robotic arm end-effector pneumatic routing
- CNC machine tool coolant line connections
- Conveyor system sensor mounting brackets
- Packaging machinery air knife assemblies
- Semiconductor FOUP purge systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads. Tighten to 2.8-3.2 N·m torque using 17mm wrench.
Avoid over-rotation beyond 210° to prevent seal deformation. Perform pressure test at 1.5× working pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPH1002 |
