Airtac X-EPH External Hex Elbow Connector X-EPH1004
$6.42
Regular price
$13.92
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH1004
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH1004 Hexagonal Elbow Joint Technical Details
- Model: X-EPH1004
- Type: External hexagonal elbow joint with swivel mechanism
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Black anodized (12-15μm thickness)
- Thread specification: M10×1.0 internal thread (ISO 6149-1 standard)
- Applicable tube OD: 8mm (flexible pneumatic tubing)
- Working pressure: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR/FKM optional
- Rotation angle: ±360° continuous rotation
- Tilt angle: ±25° maximum deflection
- Weight: 85±3g
- Dimensions: 60mm(L) × 20mm(W) × 25mm(H)
- Installation torque: 25-30 Nm (with anti-seize compound recommended)
- Vibration resistance: 10-2000Hz, 5G acceleration
Precision-machined pivot joint featuring triple-seal structure (radial seal + dual axial seals) for leak-free performance. The hardened steel pivot pin (HRC 50-55) ensures smooth rotation under load. Ideal for creating multi-axis pneumatic connections in confined spaces.
Industrial Applications:
- Multi-axis robotic end effectors in assembly lines
- Rotary tool changers for CNC machines
- Modular pneumatic circuit distribution systems
- Automated packaging machine gripper rotation units
- Semiconductor wafer handling equipment
Installation protocol:
Apply thread sealant only on male threads (not on elbow body).
Perform torque check after 48 hours of operation.
Maximum recommended pulsation frequency: 2Hz at 0.7MPa.
Matched Components:
- Optimal with AirTAC PU-08 polyurethane tubing
- Use AS-401 series adapters for metric conversion
- Pair with X-SMCK series brackets for vibration reduction
| Property | Property Value |
|---|---|
| sku | X-EPH1004 |
