Airtac X-EPH External Hex Elbow Connector X-EPH10M20
AirTAC X-EPH10M20 Hex Elbow Joint Technical Details
- Model: X-EPH10M20
- Series: X-EPH (Hexagonal Elbow Joint)
- Thread specification: M20×1.5
- Material: Aluminum alloy ADC12 (anodized black)
- Seal material: NBR (Nitrile rubber)
- Max working pressure: 0.7 MPa
- Temperature range: -20℃ to 80℃
- Rotation angle: 360° continuous rotation
- Thread engagement length: 15mm
- Surface hardness: HV 120±20
- Torque resistance: ≤15 N·m
- Weight: 53g ±2g
- Dimensions: 40mm(L) × 28mm(W) × 28mm(H)
- Port configuration: Male thread (M) to elbow joint
- Vibration resistance: 10-2000Hz, 1.5mm amplitude
- Compliance: RoHS compliant
Precision-engineered hexagonal elbow joint with full rotation capability, featuring anti-vibration locking grooves and triple-sealing structure (O-ring + thread seal + metal-to-metal contact). The anodized surface provides corrosion resistance in humid environments. Designed for high-cycle applications with 500,000+ rotation lifespan.
- Pneumatic tool torque transfer systems
- Robotic arm end-effector connections
- CNC machine coolant line routing
- Semiconductor equipment gas delivery
- Packaging machine actuator linkages
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (do not over-tighten beyond 12 N·m).
Align flow direction arrow with media path. For vertical installations,
use thread locker on adjustment nut. Test rotation torque (0.3-0.8 N·m) after assembly.
| Property | Property Value |
|---|---|
| sku | X-EPH10M20 |
