Airtac X-EPH External Hex Elbow Connector X-EPH1202
AirTAC X-EPH1202 Hex Elbow Joint Specifications
- Model: X-EPH1202
- Type: External hexagon elbow fitting (push-to-connect)
- Thread standard: Metric (M5×0.8)
- Hex size: 12mm wrench flat
- Material: Nickel-plated brass (base material: CuZn39Pb3)
- Temperature range: -20℃ to 150℃
- Max torque resistance: 14 N·m
- Operating pressure: 0~1.0 MPa
- Tube compatibility: Φ12mm OD polyurethane/nylon tubing
- Seal type: NBR O-ring (oil-resistant)
- Weight: 48g ±2g
- Dimensions: 32mm(L) × 24mm(W) × 18mm(H)
- Rotation angle: 360° continuous rotation capability
- Vibration resistance: ≤25Hz (ISO 10816-3 compliant)
Precision-engineered swivel joint featuring dual sealing surfaces and anti-vibration lock nuts. The 90° elbow design optimizes space utilization in complex pneumatic circuits while maintaining full rotational adjustment. Electroplated finish provides corrosion resistance in humid environments (salt spray tested per ASTM B117).
- Robotic end-effector pneumatic connections
- CNC machine tool coolant line routing
- Packaging machinery rotary unions
- Semiconductor fab equipment gas lines
- Automated warehouse conveyor systems
Installation protocol:
Hand-tighten until resistance is felt, then apply 1/4 turn with wrench.
Use thread sealant only on male threads (not required for push-connect side).
Maximum reconnection cycles: 15 times (recommend O-ring replacement after 10 cycles).
| Property | Property Value |
|---|---|
| sku | X-EPH1202 |
