Airtac X-EPH External Hex Elbow Connector X-EPH1204
$6.42
Regular price
$13.92
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH1204
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH1204 Hex Elbow Fitting Technical Details
- Model: X-EPH1204
- Type: External hexagon elbow joint (male thread)
- Material: Stainless steel SS304 (electroless nickel plating)
- Thread specification: M12×1.0 external thread (ISO standard)
- Hex size: 19mm wrench flat
- Max working pressure: 1.5 MPa (15 bar)
- Temperature range: -20℃ to 150℃
- Weight: 58±2g
- Dimensions:
- Total length: 46.5mm
- Thread length: 14mm
- Elbow radius: 15mm
- Body diameter: 16mm
- Surface roughness: Ra ≤3.2μm
- Torque rating: 35-40 N·m (lubricated)
- Flow coefficient (Cv): 0.85
- Vibration resistance: 10-2000Hz, 5G max
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined right-angle pneumatic connector featuring anti-vibration grooves and dual O-ring sealing (NBR 70°). The 360° rotatable elbow design enables flexible piping layouts in confined spaces. Includes integrated dust wiper for contamination prevention.
Recommended Applications:
- Robot arm end effector pneumatic connections
- CNC machine tool coolant line adapters
- Semiconductor wafer handling equipment
- Food processing machinery (NSF compliant version available)
- High-cycle automation test fixtures
Installation protocol:
Apply 2-3 drops of pneumatic sealant (PST-3 type) on threads before assembly.
Tighten using calibrated torque wrench - do not exceed 45N·m.
Re-torque after 50 operating cycles.
| Property | Property Value |
|---|---|
| sku | X-EPH1204 |
