Airtac X-EPH External Hex Elbow Connector X-EPH6M10
AirTAC X-EPH6M10 Hexagonal Elbow Joint Specifications
- Model: X-EPH6M10
- Type: Reusable 90° pneumatic elbow connector
- Thread specification: M10×1.5 (external thread)
- Hex size: 17mm across flats
- Material: Brass (Nickel-plated) or Stainless Steel (AISI 303)
- Operating pressure: 0.05-1.5 MPa
- Temperature range: -20℃ to 80℃
- Seal material: NBR (Standard), FKM (Optional)
- Surface roughness: Ra ≤3.2μm
- Tightening torque: 12-15 N·m
- Weight: ~25g
- Dimensions: 30mm (L) × 17mm (W across flats) × 15mm (H)
- Tube compatibility: Ø6mm (1/4") pneumatic tubing
Precision-machined elbow joint with hex base for wrench installation, featuring dual O-ring sealing (dynamic + static seals) for leak-free performance. The 90° design enables compact piping layouts while maintaining full flow capacity (Cv≈0.12). Corrosion-resistant finish meets ISO 9227 salt spray test standards (48h minimum).
- Space-constrained pneumatic manifolds
- Robotic end-effector tooling connections
- Packaging machine rotary union interfaces
- Medical device gas line routing
- CNC machine tool coolant control systems
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (for brass models only).
Use 17mm combination wrench for installation - do not exceed 18N·m torque.
Perform pressure test at 1.75MPa before full operation.
| Property | Property Value |
|---|---|
| sku | X-EPH6M10 |
