Airtac X-EPH External Hex Elbow Connector X-EPH6M12
$3.89
Regular price
$11.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH6M12
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH6M12 Hex Elbow Swivel Joint Technical Details
- Model: X-EPH6M12 (Right Angle Rotating Type)
- Thread Specification: M12x1.5 (Male Thread)
- Material: Carbon Steel with Nickel Plating (Body), PPS (Rotating Section)
- Seal Material: NBR (Nitrile Rubber)
- Max Working Pressure: 1.5 MPa
- Pressure Range: 0.05-1.5 MPa
- Temperature Range: -20℃ to 80℃
- Rotation Angle: 360° Continuous Rotation
- Torsional Stiffness: ≤0.3 N·m/rad
- Leakage Rate: ≤3 bubbles/min (Under 0.5 MPa air pressure)
- Weight: 32g ±2g
- Dimensions: 40mm(Total Length) × 16mm(Hex Width) × 16mm(Height)
- Surface Hardness: HV300-400 (Nickel Plated Layer)
- Protection Rating: IP40 (Standard), IP67 Available on Request
- Vibration Resistance: 10-2000Hz, 1.5mm Amplitude
Precision-engineered pivot joint featuring anti-vibration lock nuts and smooth 360° rotation capability. The chromium-molybdenum steel spring provides consistent sealing force across temperature fluctuations. Dual sealing structure prevents air leakage during rotational movement.
Industrial Applications:
- Robotic arm end effector pneumatic connections
- CNC machine tool coolant line adapters
- Semiconductor wafer handling equipment
- Automated packaging line rotary unions
- Plastic injection molding machine air circuits
- Food processing pneumatic tool quick disconnects
Installation protocol:
Apply 2.5-3.5 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contact with rotating surfaces. Perform rotational alignment before final tightening.
Lubrication:
Apply ISO VG32 turbine oil (3 drops monthly) through the grease nipple.
Compatible with air tool oil (MIL-PRF-6085 standard). Avoid silicone-based lubricants.
| Property | Property Value |
|---|---|
| sku | X-EPH6M12 |
