Airtac X-EPH External Hex Elbow Connector X-EPH6M16
$4.67
Regular price
$12.17
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPH6M16
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPH6M16 Hexagonal Elbow Joint Specifications
- Model: X-EPH6M16
- Type: External hexagon elbow pivot joint
- Body material: Carbon steel with zinc-nickel plating
- Thread specification: M16×1.5 male thread (ISO 6149 standard)
- Tube compatibility: 6mm OD pneumatic tubing
- Swivel angle: 360° continuous rotation
- Max working pressure: 1.0 MPa (145 psi)
- Temperature range: -20℃ to 80℃
- Surface hardness: 550-650 HV (Vickers hardness)
- IP rating: IP54 (dust protected & splash resistant)
- Certification: RoHS compliant
- Installation torque: 25-30 N·m recommended
- Weight: 65g ±2g
- Dimensions: 50mm(L) × 25mm(W) × 25mm(H)
Precision-engineered pivot joint featuring dual-sealed ball bearing mechanism for smooth rotation under load. The corrosion-resistant zinc-nickel coating provides 500hr+ salt spray protection. Optimized flow path design reduces pressure drop by 18% compared to standard elbows.
Typical Applications:
- Robotic arm end-effector pneumatic connections
- CNC machine tool coolant line adapters
- Packaging machine rotary union interfaces
- Automated assembly line tooling changers
- Semiconductor wafer handling equipment
Installation guidelines:
Use two wrenches during assembly - one to hold hex base (19mm) and
another to tighten swivel nut (22mm). Apply pipe sealant only on male
threads, avoiding contact with ball joint surfaces. Max re-tightening
cycles: 5 times.
| Property | Property Value |
|---|---|
| sku | X-EPH6M16 |
