Airtac X-EPH External Hex Elbow Connector X-EPH6M20
AirTAC X-EPH6M20 Hexagonal Elbow Joint Technical Details
- Model: X-EPH6M20
- Type: External hexagonal swivel joint
- Thread specification: M20×1.5 male thread
- Material: Brass construction with nickel plating
- Max torque resistance: 45 N·m
- Pressure range: 0-1.0 MPa (145 psi)
- Temperature range: -20℃ to 120℃
- Swivel angle: 360° continuous rotation
- Hex size: 24mm across flats
- Seal type: NBR O-ring (oil-resistant)
- Weight: 60g ±2g
- Dimensions: 35mm(L) × 20mm(W) × 20mm(H)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-engineered elbow joint featuring a reinforced hexagonal collar for secure wrench gripping during installation. The chrome-plated brass body ensures corrosion resistance in humid environments while maintaining smooth swivel action under pressure. Designed with dual sealing grooves for enhanced leak prevention.
- Pneumatic tool quick-connect systems
- Robotic arm end-effector connections
- Compressed air distribution networks
- CNC machine coolant line routing
- Food processing equipment (FDA-compliant lubricants used)
Installation protocol:
Apply thread sealant to male threads (PTFE tape recommended).
Tighten using a calibrated torque wrench to 35-40 N·m maximum.
Perform pressure test at 1.5× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPH6M20 |
