Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF1003
AirTAC X-EPHF Series Toggle Joint Connector - X-EPHF1003 Technical Details
- Model: X-EPHF1003
- Type: Multi-axis pivot joint with male-threaded ends
- Material: Aluminum alloy body (A6061-T6) + Stainless steel pivot (SUS304)
- Thread specification: M10×1.5 male threads (both ends)
- Max working pressure: 0.05-0.7 MPa
- Temperature range: -20°C to 80°C
- Static load capacity: 1,470N radial / 980N axial
- Angular misalignment: ±3° (static) / ±1.5° (dynamic)
- Surface treatment: Hard anodized (body) / Electropolished (pivot)
- Seal material: HNBR o-rings (high nitrile)
- Torque rating: 4.9 N·m max (dynamic) / 9.8 N·m (static)
- Weight: 228g ±5g
- Dimensions: 89mm(L) × 32mm(W) × 32mm(H)
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision multi-articulation connector designed for complex pneumatic circuit routing in confined spaces. Features zero-backlash ball-and-socket design with self-lubricating composite bushings. Certified for ISO 16028 flange face seal compatibility. Includes anti-vibration thread locking patches pre-applied.
- Robotic wrist joint pneumatic line connections
- Multi-axis CNC tool changer manifolds
- Semiconductor wafer handling equipment
- Automated packaging machine rotary unions
- Precision medical device assembly systems
Installation protocol:
Apply PTFE-based thread sealant (not included) and torque to 12-15 N·m.
Perform angular alignment calibration before final tightening.
Maximum recommended oscillation angle: 25° during dynamic operation.
| Property | Property Value |
|---|---|
| sku | X-EPHF1003 |
