Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF1004
AirTAC X-EPHF Tandem Toggle Joint X-EPHF1004 Technical Specifications
- Model: X-EPHF1004
- Type: Tandem elbow joint with floating mechanism
- Material: Carbon steel (SCM435) with black oxide coating
- Thread size: M10 × 1.25 (female thread both ends)
- Max. operating pressure: 50 MPa
- Rotation angle: ±25° axial rotation, ±5° radial deflection
- Static load capacity: 2,450 N (radial), 1,470 N (axial)
- Dynamic load capacity: 1,960 N (radial), 980 N (axial)
- Weight: 0.38 kg ±2%
- Dimensions: 98mm(Total Length) × 34mm(Ø) × 16mm(Flange Thickness)
- Temperature range: -30℃ to 120℃ (with standard grease)
- Surface hardness: HRC 45-50
- Torque resistance: 29.4 N·m max
- Vibration resistance: 10-2000 Hz, 30 m/s² max
Precision-engineered tandem toggle joint featuring a dual-axis compensation design that absorbs both parallel and angular misalignment. The through-hole structure minimizes stress concentration, while the hardened steel construction ensures 200,000+ cycles at rated load. Includes integrated dust seals and pre-lubricated with high-viscosity silicone grease.
- Multi-axis robotic arm wrist connections
- CNC machine tool coolant line adapters
- High-vibration pneumatic conveying systems
- Semiconductor wafer handling equipment
- Automated welding torch positioning units
Installation protocol:
Apply 20-25 N·m torque during assembly using a crowfoot wrench.
Perform alignment check every 500 operating hours.
Avoid side-impact loads exceeding 300N during operation.
| Property | Property Value |
|---|---|
| sku | X-EPHF1004 |
