Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF10M16
AirTAC X-EPHF Series Tandem Elbow Joint - X-EPHF10M16 Technical Details
- Model: X-EPHF10M16
- Type: Tandem elbow union joint (360° rotatable)
- Thread specification: M16×1.5 male thread both ends
- Material: Cold-forged stainless steel (SUS303)
- Rotation angle: ±5° axial misalignment compensation
- Max torque resistance: 12 N·m
- Pressure rating: 0.2-1.0 MPa
- Temperature range: -20℃ to 150℃
- Seal material: HNBR with PTFE coating
- Installation orientation: Omnidirectional (horizontal/vertical)
- Weight: 65±2g
- Dimensions: 30mm(Length) × 16mm(Width) × 16mm(Height)
- Surface treatment: Electroless nickel plating (8-12μm)
Precision tandem elbow joint featuring dual-axis compensation for complex pneumatic line routing. The hexagonal socket design allows tool-free 360° rotation adjustment while maintaining leak-proof performance under vibration. Optimized internal flow path reduces pressure drop by 18% compared to standard elbows.
- Multi-axis robotic arm pneumatic connections
- High-cycle packaging machinery with space constraints
- Semiconductor wafer handling equipment
- Medical gas delivery systems requiring hygienic fittings
- Mobile hydraulic test bench setups
Installation protocol:
Apply thread sealant only on male threads (not on flange surfaces).
Tighten to 8-10 N·m torque using 22mm wrench.
Perform pressure test at 1.5× operating pressure after installation.
| Property | Property Value |
|---|---|
| sku | X-EPHF10M16 |
