Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF1202
AirTAC X-EPHF Series Tandem Elbow Joint X-EPHF1202 Technical Details
- Model: X-EPHF1202 (Standard rotation type)
- Series: X-EPHF1200 Heavy Duty Series
- Body material: Nickel-plated brass (C3604)
- Seal material: NBR (Nitrile rubber)
- Thread specification: Rc1/8 (Female thread both ends)
- Maximum working pressure: 1.5 MPa
- Proof pressure: 2.25 MPa
- Burst pressure: 3.0 MPa
- Operating temperature: -5℃ to 80℃ (No freeze)
- Allowable angular misalignment: ±5° (Axial direction)
- Rotation torque: ≤0.3 N·m (At 0.7 MPa air pressure)
- Weight: 112±5g
- Dimensions: 52mm(Length) × 28mm(Width) × 38mm(Height)
- Surface treatment: Electroless nickel plating (5-8μm thickness)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
High-precision tandem elbow joint designed for multi-axis pneumatic systems requiring compound angle compensation. Features dual O-ring seals with staggered groove design for enhanced leak protection under dynamic movement. The 360° free rotation capability reduces hose torsion stress during robotic arm movements.
- Multi-axis robotic welding arms (automotive assembly lines)
- Semiconductor wafer handling equipment
- Packaging machinery with rotating turret systems
- CNC machine tool automatic tool changers
- Food processing conveyor diverters
Installation guidelines:
Apply silicone-free lubricant to O-rings before assembly.
Tighten to 14-16 N·m torque using crowfoot wrench.
Maximum allowable pulsation: 1.2 million cycles at 0.5Hz swinging motion.
- Use with AIRTAC SMCV-06 velocity control valves for motion damping
- Combine with PISCO HOS-6φPU pneumatic hoses (6mm ID)
- For vacuum applications: Add VR-12 vacuum retention collar
| Property | Property Value |
|---|---|
| sku | X-EPHF1202 |
