Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF1203
$5.49
Regular price
$12.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPHF1203
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPHF Series Tandem Elbow Joint X-EPHF1203 Technical Details
- Model: X-EPHF1203
- Type: Tandem elbow joint with female thread
- Material: Anodized aluminum alloy body + POM (Polyoxymethylene) rotating parts
- Working pressure: 0.05–0.7 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Port size: 1/8" BSPP female threads (G1/8)
- Rotation angle: ±25° adjustable deflection
- Torque limit: 0.5 N·m max
- Weight: 118±3g
- Dimensions: 53mm(L) × 32mm(W) × 32mm(H)
- Surface hardness: HV 400-450 (anodized layer)
- Installation torque: 1.2-1.5 N·m recommended
- Vibration resistance: 10-2000 Hz, 15G acceleration
- IP rating: IP54 (standard configuration)
High-precision articulated joint featuring dual-axis compensation for complex piping alignment. The chrome-plated steel pivot mechanism ensures smooth rotation cycles exceeding 500,000 repetitions. Optimized flow path design maintains 95% original tube ID for minimal pressure drop.
Primary Applications:
- Robotic arm end effector pneumatic connections
- CNC machine tool coolant line articulation
- Semiconductor wafer handling vacuum systems
- Packaging machinery with oscillating motion modules
- Automated test equipment requiring vibration isolation
Installation guidelines:
Apply thread sealant only on male threads (PTFE tape recommended).
Avoid overtightening - use torque wrench for precise installation.
Lubricate pivot points with silicone grease (NLGI #1 grade) every 2,000 operating hours.
Flow performance:
Maximum flow rate 350 NL/min at 0.5 MPa with 6mm bore tubing.
Compatible with ISO 15407-1 standard polyurethane/nylon tubing.
| Property | Property Value |
|---|---|
| sku | X-EPHF1203 |
