Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF1204
AirTAC X-EPHF1204 Tandem Toggle Joint Specifications
- Model: X-EPHF1204
- Type: Series connection toggle joint (female thread both ends)
- Body material: Nickel-plated brass
- Seal material: NBR rubber
- Port size: 1/8" NPT/BSP
- Max working pressure: 0.05-0.7 MPa
- Temperature range: -20℃ to 80℃
- Torque limit: ≤2.5 N·m
- Thread engagement depth: 7.5±0.5mm
- Surface treatment: Electroplated + chromate conversion coating
- Weight: ~85g
- Dimensions: 52mm(L) × 24mm(W) × 24mm(H)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
- Protection rating: IP54 (standard sealing)
Precision-engineered tandem joint featuring 360° adjustable swivel motion with zero leakage design. The hexagonal body structure allows tool-assisted tightening and provides 6 contact surfaces for secure grip. Specialized anti-vibration thread design prevents loosening under cyclic loads.
- Multi-axis robotic arm articulation systems
- CNC machine tool automatic tool changers
- Pharmaceutical packaging line pneumatic circuits
- Semiconductor wafer handling equipment
- Automated assembly line positioning mechanisms
Installation protocol:
Use open-end wrench on flat surfaces (do NOT use pipe wrench).
Apply 1.5-2 wraps of PTFE tape on male threads.
Tighten until joint is finger-tight plus 1/2-3/4 turn with tool.
Avoid over-torqueing to prevent brass deformation.
| Property | Property Value |
|---|---|
| sku | X-EPHF1204 |
