Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF12M12
AirTAC X-EPHF Series Tandem Swivel Joint Specifications
- Model: X-EPHF12M12
- Type: Tandem swivel joint with male threads
- Body material: High-strength nickel-plated brass
- Seal material: HNBR (Hydrogenated Nitrile) rubber
- Thread specification: M12×1.0 male (external)
- Operating temperature: -20℃ to 150℃
- Max swivel angle: ±25° per joint section
- Pressure range: 0.05-1.0 MPa
- Torque resistance: ≤0.3 N·m at 0.5 MPa
- Mounting orientation: Omnidirectional (360° rotatable)
- Leakage rate: ≤3 bubbles/min (ISO 16007 test)
- Weight: 112±5g
- Dimensions: 42mm(Ø) × 58mm(L) (per joint unit)
- Vibration resistance: 10-2000Hz, 15G acceleration
- Protection rating: IP54 (standard sealing)
Modular tandem swivel joint designed for complex pneumatic routing in confined spaces. Features double ball-bearing structure for smooth multi-axis rotation and integrated dust wipers. Compatible with ISO 1179-1 and DIN 3852 standards. Requires PTFE tape or liquid sealant during installation.
- Robotic welding gun cooling line connections
- CNC tool changer pneumatic circuits
- Semiconductor wafer handling arms
- Automotive assembly line torque tools
- Packaging machine rotating platforms
Maintenance note:
Lubricate with ISO VG32 pneumatic oil every 500,000 cycles. Avoid
side-load forces exceeding 50N during operation. Maximum recommended
rotation speed: 30 RPM continuous.
| Property | Property Value |
|---|---|
| sku | X-EPHF12M12 |
