Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF12M16
AirTAC X-EPHF12M16 Tandem Elbow Joint Technical Specifications
- Model: X-EPHF12M16
- Type: Tandem swivel joint with male threads
- Thread specification: M16×1.5 (ISO 6149 metric thread)
- Material: Anodized aluminum body + Chrome-plated steel ball
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃ (non-condensing)
- Max rotation angle: ±30° axial tilt, 360° continuous rotation
- Torque resistance: ≤0.3 N·m at 0.5 MPa
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE backup ring
- Surface hardness: HV400±50 (ball surface)
- Leakage rate: ≤3 bubbles/min (ISO 9978 test standard)
- Protection rating: IP54 (dust-protected & splash-resistant)
- Weight: 198±5g (with protective caps)
- Dimensions: 70mm(L) × 35mm(W) × 25mm(H)
Precision tandem elbow joint featuring zero-clearance ball retention technology, optimized for multi-axis pneumatic systems requiring compact routing solutions. The dual-seal labyrinth design prevents particulate ingress while maintaining smooth articulation. Includes anti-vibration thread lock patches for stable connections.
- Multi-axis robotic end effectors (SCARA/articulated arms)
- Rotary index table pneumatic supply lines
- Tool-changing mechanisms in CNC automation
- Packaging machine rotary union connections
- Semiconductor wafer handling equipment
Installation protocol:
Apply 12-15 N·m torque during assembly using flank-contact wrench.
Perform 50 full rotation cycles before pressure application to seat seals.
Replace O-rings every 500,000 cycles in high-vibration environments.
| Property | Property Value |
|---|---|
| sku | X-EPHF12M16 |
