Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF12M20
$7.05
Regular price
$14.55
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPHF12M20
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPHF12M20 Toggle Joint Connector - Series X-EPHF Specifications
- Model: X-EPHF12M20
- Type: Tandem toggle joint (swivel connector)
- Thread specification: M20×1.5 male thread (external)
- Material: Nickel-plated brass body + reinforced PPS composite
- Rotation angle: ±25° free swivel with 360° axial rotation
- Working pressure: 0.2-1.0 MPa (29-145 PSI)
- Temperature range: -10℃ to 80℃ (14°F to 176°F)
- Mounting style: In-line tandem configuration
- Seal material: HNBR rubber with PTFE anti-friction coating
- Max torque resistance: 12 N·m
- Surface treatment: Anti-corrosion anodized layer (5-8μm)
- Weight: 318g ±5g
- Dimensions: 72mm(L) × 42mm(W) × 42mm(H)
- Vibration resistance: 5-2000Hz, 20G acceleration
- Protection rating: IP40 (dust protected)
High-precision tandem toggle joint designed for multi-axis pneumatic systems requiring compound angular adjustments. Features dual-stage sealing with leak rate <0.1 Nl/min under 0.5MPa. The chromium-hardened pivot pin ensures 500,000+ cycles at rated load.
Typical Applications:
- Robotic arm end-effector tool changers
- CNC machine multi-directional coolant nozzles
- Automated packaging line rotary actuators
- Semiconductor wafer handling vacuum systems
- Automotive paint robot fluid delivery arms
Installation note:
Apply lithium-based grease (NLGI #2) to pivot points during assembly.
Use counter-rotation method during tightening - hold base fitting at 30N·m torque
while rotating connector body. Avoid exceeding 45° cumulative bend angle in dynamic applications.
| Property | Property Value |
|---|---|
| sku | X-EPHF12M20 |
