Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF4M5
$3.79
Regular price
$11.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPHF4M5
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPHF4M5 Series Tandem Hinge Joint Technical Details
- Model: X-EPHF4M5
- Type: Tandem hinge joint (multi-directional pivot)
- Body material: Anodized aluminum alloy (AL6061-T6)
- Thread specification: M5×0.8 female thread (dual ports)
- Max rotation angle: ±5° axial deflection
- Static load capacity: 120N radial / 80N axial
- Operating temperature: -20℃ to 80℃
- Pressure rating: 0.05-1.0 MPa
- Seal type: Double-lip NBR o-ring (oil resistant)
- Surface hardness: HV400±50
- Weight: 28g ±0.5g
- Dimensions: 32mm(L) × 18mm(W) × 18mm(H)
- Mounting torque: 0.8-1.2N·m (thread engagement)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision alignment connector featuring dual-axis compensation for pneumatic systems requiring angular misalignment absorption. The nickel-plated brass internal pivot mechanism ensures smooth rotation cycles exceeding 500,000 repetitions. Compatible with ISO 6432 pneumatic cylinders.
Ideal Applications:
- Robotic end-effector tool changers
- Conveyor system diverters with floating connections
- Semiconductor wafer handling arms
- Packaging machine rotary table interfaces
- Automated welding torch positioning units
Installation protocol:
Apply medium-strength thread locker (Loctite 243 recommended) on male threads.
Perform alignment check after 50 operational cycles. Avoid overtightening -
use torque wrench with 6mm hex key (JIS standard).
| Property | Property Value |
|---|---|
| sku | X-EPHF4M5 |
