Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF4M6
AirTAC X-EPHF Series Tandem Elbow Joint - X-EPHF4M6 Technical Details
- Model: X-EPHF4M6
- Type: Multi-axis adjustable tandem elbow joint
- Thread specification: M6×1 male thread (ISO 1179)
- Material: Stainless steel body + brass rotating components
- Surface treatment: Nickel plating (3-5μm thickness)
- Operating temperature: -20℃ to 150℃
- Max torque resistance: 2.5 N·m
- Pressure rating: 1.0 MPa (10 bar)
- Weight: 15g ±0.5g
- Dimensions: 25mm(L) × 12mm(Ø) × 12mm(Rotation diameter)
- Rotation angle: 360° continuous swivel + ±15° axial tilt
- Seal material: FKM fluorocarbon rubber (-20℃~200℃)
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined tandem elbow for complex pneumatic routing, featuring dual-axis adjustability with zero leakage. Electroplated surfaces provide corrosion resistance in humid environments. The through-hole design maintains consistent airflow (Cv=0.12) while allowing 540° cumulative positioning flexibility.
- Multi-jointed robotic arm end effectors
- Compact pneumatic circuit manifolds
- CNC machine tool cooling line adapters
- Semiconductor wafer handling equipment
- Packaging machine rotary union connections
Mounting protocol:
Hand-tighten initially, then apply 1/4 turn with 6mm wrench.
Use PTFE tape on threads for gas applications. Max 3 consecutive
joints recommended per circuit. Compatible with 4mm OD
polyurethane/nylon tubing (0.5-1.2mm wall thickness).
| Property | Property Value |
|---|---|
| sku | X-EPHF4M6 |
