Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF6M10
$3.79
Regular price
$11.29
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
X-EPHF6M10
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
AirTAC X-EPHF Series Tandem Swivel Joint - X-EPHF6M10 Technical Details
- Model: X-EPHF6M10
- Type: Tandem swivel elbow joint (male thread)
- Thread specification: M10×1.5 (metric) / 7/16"-20 UNF optional
- Material: Aluminum alloy 6063-T5 (hard anodized surface)
- Seal ring: HNBR (Hydrogenated Nitrile) with PTFE coating
- Max working pressure: 1.5 MPa (217 psi)
- Proof pressure: 2.25 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -20°C to +80°C (-4°F to 176°F)
- Swivel angle: ±25° adjustable rotation
- Surface hardness: HV 400±50 (anodized layer)
- Weight: 53±2g
- Dimensions: 60mm(L) × 30mm(W) × 30mm(H)
- Vibration resistance: 10-2000Hz, 15G acceleration
- ISO standard: 14743 (pneumatic fluid power - cylinder mounting)
High-precision tandem swivel joint featuring dual-axis rotation capability for complex piping layouts. The chrome-free anodization provides exceptional corrosion resistance in humid environments. Integrated anti-vibration grooves reduce stress concentration during dynamic operations.
Ideal Applications:
- Multi-axis robotic arm end effectors
- CNC machine tool coolant line connections
- Semiconductor wafer handling equipment
- Food processing pneumatic systems (FDA-compliant grease option)
- Mobile hydraulic test bench manifolds
Installation protocol:
Apply 2-3 wraps of PTFE tape on male threads (grade B class).
Tighten to 14-16 N·m torque using crowfoot wrench.
Avoid angular misalignment exceeding 3° during final assembly.
| Property | Property Value |
|---|---|
| sku | X-EPHF6M10 |
