Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF6M12
AirTAC X-EPHF Series Tandem Hinge Joint - X-EPHF6M12 Technical Details
- Model: X-EPHF6M12
- Type: 360° swivel tandem hinge joint (male thread)
- Thread specification: M12×1.0 male (ISO 1179 standard)
- Material: Nickel-plated brass body + POM polymer bearing
- Max rotation angle: ±5° axial deflection / 360° continuous rotation
- Pressure rating: 0.2-1.0 MPa (29-145 psi)
- Temperature range: -20℃ to 80℃ (NBR seals)
- Torque resistance: ≤0.8 N·m max rotational torque
- Flow coefficient: Cv 0.15
- Weight: 85±3 grams
- Dimensions: 40mm(L) × 20mm(W) × 20mm(H)
- Vibration resistance: 10-60Hz, 1.5mm amplitude
- IP rating: IP54 (dust protected, splash resistant)
- Certification: RoHS compliant
Precision-engineered swivel joint featuring dual-row ball bearing structure for smooth multi-axis rotation. The chromium-plated brass construction prevents galvanic corrosion when used with steel fittings. Optimized internal flow path reduces pressure drop by 18% compared to standard elbows.
- Robotic end-effector tool changers requiring flexible air supply
- CNC machine coolant line connections
- Automated packaging equipment with rotating arms
- Plastic injection molding machine ejector systems
- Semiconductor wafer handling robotics
- Welding robot gas line connections
Installation protocol:
Apply 2-3 drops of ISO VG32 pneumatic oil to bearing surfaces monthly.
Use backup wrench on hex flats (14mm) during assembly to prevent housing distortion.
Max recommended tightening torque: 12 N·m.
| Property | Property Value |
|---|---|
| sku | X-EPHF6M12 |
