Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF6M20
AirTAC X-EPHF Series Tandem Swivel Joint Specifications
- Full model: X-EPHF6M20
- Type: Tandem swivel joint with male thread
- Body material: Stainless steel SS304
- Seal material: NBR (Nitrile rubber)
- Thread specification: M20×1.5 external thread (ISO metric)
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Temperature range: -20℃ to 80℃ (NBR seals)
- Rotation angle: ±15° axial misalignment compensation
- Flow coefficient (Cv): 0.15
- Surface treatment: Passivation treatment
- Installation torque: 10-12 N·m recommended
- Weight: 198g ±3g
- Dimensions: 50mm (L) × 25mm (W) × 25mm (H)
- Vibration resistance: ≤10 Hz (continuous), ≤50 Hz (instant)
- Protection class: IP54 (standard sealing)
Precision tandem swivel joint designed for multi-axis pneumatic systems requiring compound angle compensation. Features low-torque rotation with PTFE-coated bearing surfaces reducing operational friction by 40% compared to standard models. The dual-seal labyrinth structure prevents particulate ingress in dusty environments.
- Robotic welding arm end effectors
- CNC tool changer pneumatic circuits
- Automated packaging line rotary unions
- Semiconductor handling equipment
- Food processing rotary indexing tables
Maintenance note:
Apply silicone-free lubricant (ISO VG32 equivalent) quarterly
through the zerk fitting. Maximum allowable side load: 50N.
Avoid UV exposure for permanent installations.
| Property | Property Value |
|---|---|
| sku | X-EPHF6M20 |
