Airtac X-EPHF Connector - In-Line Swivel Elbow X-EPHF6M5
AirTAC X-EPHF Series Tandem Hinge Joint X-EPHF6M5 Specifications
- Model: X-EPHF6M5
- Type: Tandem swivel joint with female thread
- Thread specification: M5×0.8 (internal)
- Material: Stainless steel (SUS303) / Aluminum alloy body
- Max working pressure: 1.0 MPa
- Temperature range: -20℃ to 80℃
- Rotation angle: ±15° axial tilt / 360° free rotation
- Seal material: HNBR (Hydrogenated Nitrile) with PTFE coating
- Weight: 28g ±1g
- Dimensions: 24mm(Ø) × 45mm(L)
- Port-to-port length: 32mm (center distance)
- Surface treatment: Electroless nickel plating
- Leakage rate: ≤3×10⁻² Pa·m³/s under rated pressure
- Vibration resistance: 10-2000Hz, 15G acceleration
- Protection rating: IP54 (standard configuration)
Precision tandem hinge joint featuring dual-axis compensation for misalignment absorption in compact pneumatic systems. The 3-layer HNBR/PTFE composite seal ensures zero leakage during dynamic rotation. Nickel-plated surfaces provide corrosion resistance in humid environments. Optimized flow path design reduces pressure drop by 18% compared to standard joints.
- Multi-axis robotic arm end effectors
- Semiconductor wafer handling equipment
- High-cycle automated packaging lines
- Cleanroom-compatible machinery
- Precision pneumatic measurement devices
- Mobile hydraulic/pneumatic hybrid systems
Installation protocol:
Apply 2-3 drops of ISO VG32 pneumatic oil to the rotating interface before initial use.
Tighten with 0.8-1.2 N·m torque using a crowfoot wrench to prevent oval deformation.
Avoid simultaneous axial and radial load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | X-EPHF6M5 |
