Airtac X-EPY Connector - Y Type Tee X-EPY6
AirTAC X-EPY6 Y-Type Tee Fitting Specifications
- Model: X-EPY6
- Type: Y-shaped three-way pneumatic connector
- Material: Brass (CuZn39Pb3) with surface nickel plating
- Thread standard: Metric (M5 × 0.8)
- Max working pressure: 1.0 MPa (145 psi)
- Proof pressure: 1.5 MPa
- Burst pressure: ≥3.0 MPa
- Temperature range: -5℃ to 80℃ (with NBR seals)
- Seal material: NBR (Nitrile rubber)
- Weight: 28g ±2g
- Dimensions: 19.5mm (L) × 19.5mm (W) × 30.4mm (H)
- Flow capacity: 350 NL/min (at 0.5 MPa)
- Surface roughness: Ra ≤3.2μm
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-machined Y-branch connector featuring triple-port configuration for compact pneumatic circuit layouts. The 60° angled branch optimizes airflow distribution while minimizing pressure drop. Nickel plating provides corrosion resistance in humid environments. Compatible with ISO 15407-1 standard fittings.
- Pneumatic tool air distribution systems
- Multi-axis robotic end effector controls
- PLC-controlled automation manifolds
- Medical device gas line splitting
- Packaging machine actuator networks
Installation guidance:
Apply 2-3 N·m torque during assembly. Use thread sealant only on male threads,
avoiding contamination of internal flow paths. Align branch port within ±5°
of intended flow direction.
| Property | Property Value |
|---|---|
| sku | X-EPY6 |
