Airtac 2KWX Fluid Solenoid Valve 2KWX03006B
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03006B Fluid Solenoid Valve Specifications
- Model: 2KWX03006B
- Type: 2-position, 3-way direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.05–1.0 MPa
- Voltage options: DC24V (±10%), AC220V (50/60Hz)
- Flow rate: 850 L/min (ANR)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 0.58 kg
- Dimensions: 90mm(L) × 44mm(W) × 67mm(H)
- Seal material: FKM (Fluorocarbon Rubber)
- Temperature range: -5℃ to 80℃ (with anti-freeze measures below 0℃)
- Power consumption: 4.8W (DC24V), 5.5VA (AC220V)
- Protection rating: IP67 (dustproof & waterproof)
- Port thread depth: 12mm (minimum engagement)
High-flow solenoid valve with copper-free aluminum alloy body, designed for aggressive media control. Features manual override button for system debugging and maintenance. Requires 50μm filtration (25μm recommended for viscous fluids). Compatible with air, water, and light oils (ISO VG32 or lower).
- Industrial automation: Pneumatic cylinder control systems
- Food processing: Beverage dispensing equipment
- Water treatment: Chemical dosing systems
- Packaging: Vacuum suction cup circuits
- Semiconductor: Cooling water control
Installation guidelines:
Mount with 20cm minimum upstream straight piping. Use vibration-damping
brackets if ambient vibration exceeds 5G. Lubricate seals with
silicone grease (Parker O-Lube 111 recommended) during maintenance.
| Property | Property Value |
|---|---|
| sku | 2KWX03006B |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC24V |
