Airtac 2KWX Fluid Solenoid Valve 2KWX03006F
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03006F Fluid Solenoid Valve Specifications
- Model: 2KWX03006F
- Type: 3-position, 5-way (5/3) closed center
- Port size: G3/8 (ISO228/1 standard)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Voltage options: DC24V (±10%), AC220V 50/60Hz
- Weight: 450g ±3% (without connectors)
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H)
- Flow capacity: 1800 l/min (Cv=1.8)
- Seal material: Fluororubber (FKM) standard (NBR optional)
- Temperature range: -5℃ to 80℃ (fluid temp)
- Power consumption: 4.8W (DC24V), 5.5VA (AC220V)
- Response time: ≤30ms (exhaust to full pressure)
- Protection rating: IP67 (connector installed)
- Port thread depth: 12mm (minimum engagement)
High-flow proportional control valve with closed-center configuration, engineered for precision fluid regulation in hydraulic/pneumatic hybrid systems. Features dual-coil latching design for energy efficiency and stainless steel plunger for chemical resistance. Requires 25μm filtration (βₙ≥75) upstream.
- Industrial cleaning machine fluid circuits
- Plastic injection molding hydraulics
- Coolant control in CNC machining centers
- Water treatment plant dosing systems
- Food processing pneumatic actuators
Installation protocol:
Mount with vibration-damping gaskets when used in mobile equipment.
Maintain 15° maximum angular deviation from vertical axis.
Always bleed residual pressure before disassembly.
| Property | Property Value |
|---|---|
| sku | 2KWX03006F |
| Port Size | PT1/8 |
| Flow Aperture | 1.5mm |
| Coil Voltage | DC12V |
