Airtac 2KWX Fluid Solenoid Valve 2KWX03008A
2. Wide pressure range adaptability – options include Ultra-High Pressure (X), High Pressure (H), Standard, and Large Flow (L) configurations;
3. Compact structure with minimized footprint, lightweight design, and tool-free assembly/disassembly capability;
4. Brass valve body construction with Class B thermal-rated coil. Standard FPM (Fluorocarbon Rubber) seals ensure compatibility with multiple media. Custom seal materials available upon consultation with our technical department;
5. IP65-rated coil protection, available in direct lead wire or DIN connector wiring configurations.
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2KWX Series
AirTAC 2KWX03008A Fluid Solenoid Valve Technical Details
- Model: 2KWX03008A
- Type: 2-position, 3-way normally closed (direct-acting)
- Port size: G1/8 (BSPP thread)
- Operating pressure range: 0.05–1.0 MPa
- Voltage variants: DC12V (±10%), DC24V (±10%), AC110V (±10% 50/60Hz), AC220V (±10% 50/60Hz)
- Flow coefficient (Cv): 1.2
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 320g ±5% (with coil)
- Dimensions: 60mm(L) × 40mm(W) × 85mm(H) (including connectors)
- Seal material: Fluorocarbon rubber (FKM) standard, optional HNBR/NBR
- Temperature range: -10℃ to 80℃ (FKM seals), expandable to 120℃ with HNBR option
- Power consumption: 2.5W (DC24V), 3.2VA (AC220V)
- Protection class: IP67 (coil), IP65 (valve body)
- Port alignment: ISO 5599-1 compliant
- Max viscosity: 300 cSt
- Hysteresis: ≤10% of rated voltage
High-flow fluid control valve with brass body and corrosion-resistant plating, designed for aggressive media including compressed air, water-oil mixtures, and light hydraulic fluids. Features manual override capability and explosion-proof coil options (Ex II 2G Ex e IIC T6). Requires 25μm filtration for optimal performance.
- Coolant flow control in CNC machining centers
- Lubrication system sequencing
- Beverage dispensing system fluid management
- Wastewater treatment plant pneumatic actuators
- Semiconductor wet bench chemical distribution
Installation guidelines:
Mount with flow direction arrow aligned to piping. Allow 15mm clearance
around coil for heat dissipation. Use vibration-damping mounts when
installed near pumps or motors. For viscous fluids, preheat to ≤50℃
before system startup.
| Property | Property Value |
|---|---|
| sku | 2KWX03008A |
| Port Size | PT1/4 |
| Flow Aperture | 1.5mm |
| Coil Voltage | AC220V |
